1956 Acquisition of license to manufacture batch mills
A special agitator shaft with symmetrically arranged agitator pegs and sleeves of tungsten carbide for wear protection devel- Vertical, batch operation mill for the preparation of tungsten Ideal flow behaviour due to a special agitator peg arrange-ment and the hemispherically shaped chamber floor integrated screen plate for grinding media separationIntensive cooling through a double-wall grinding tank and cooled circulation pipeline
-
-
Development of the first continuous agitator bead mill
Product inlet via rotor / immersion tube system prevents back flow of grinding media into the feed line.
-
-
Bottom up & Top down
Generally, there are two ways to obtain nano-powders. A bottom-up manufacturing method (bottom up) for chemical methods, such as chemical precipitation, sol-gel process (sol-gel),... Another method is physical method, which changes the powder particles from big to small (top down), such as mechanical ball milling,... And so on.
-
-
Horizontal Disk Grinding Machines
The Development In 1963, the first vertical agitator was developed internationally, the first horizontal agitator was developed in 1975, the first horizontal agitator bead mill with eccentric disks was introduced to the public and the horizontal disc grinder was introduced， in 2004, which became the industry standard. In the following years, the grinding media separation systems, the geometry of the grinding disks and the various grinding chamber materials were further developed.
-
-
Rod-pin nano-grinding Technology
The grinding system pin nanomill shows the evolutionary develop- ment of system with the rotor-slotted pipe separating system. The enclosed horizontal agitator mill is designed for highest product throughput rates and possesses a pin grinding system for highest grinding intensity.
-
-
Ceramic comminution chamber technology
In 2011, we developed the first zirconia comminution chamber technology in China. It has no metal ion pollution and is used in batteries, pharmaceuticals, glazes, ink and food.
主要特點：
*物料研磨細度*小可達亞微米級別≤0.03 μm
*合理的研磨腔德系三偏心凸輪盤式設計，是大量實驗數據的結果，并按一定流體力學順序排列。
*整個研磨腔體徑向受力， 大面積三偏心凸輪盤產生高密度..
整機采用德國DIN技術標準設計和制造工藝
諾研盤式砂磨機，臥式結構，驅動單元位于機架內或上端，有利于驅動效率和扭矩的提升，研磨腔采用先進偏心盤式結構，研磨強度更高、剪切力更大，鋯球的運動速度更均勻，得到的粒度分布更窄，研磨粉碎腔無死角區。
上海諾研棒銷納米砂磨機，研磨強度更加集中，粉碎腔采用短腔體設計，轉子采用大直徑設計，讓鋯球的研磨能量聚集于定子桶內壁，研磨后得到一個分布較窄的粒度分布，產品的一致性更高。
上海諾研機械密封，采用雙端面設計，陶瓷合金材料密封環，進口密封圈，耐溶劑，保證砂磨機高速運轉時不泄漏，同時大大提高了機械密封的使用壽命。
